Adding Background Images To Your Map

You can place a background image on a map so that it appears behind the devices, icons, and links on the map. All image file formats supported for custom icons can be used.

• You might use a background image containing a floor plan of an office, and move the items on the map to show the locations of each device in the office.
• You might use an image containing a street map of a city or topographic map of a county or state.

The figure below shows a map after placing an image in the background.

To place a background image in your map:

• Drag an image file from a desktop folder to the map window.

or

1. From the Appearance section of the Map Settings window, available from the Edit menu, choose Background. The Background pane appears, showing the current background image, if there is one.
2. Click to select Use background image.


Map with background image.

Tips for Using Background Images

Image size

The background image retains its height and width, and is not scaled (stretched or shrunk) when you resize the window. If the background image is smaller than the current window size, the image will be centered in the map, and the map's background color will show around the edges. If a large image is placed, its dimensions determine the full size of the window.

Image contrast and brightness

Contrasty images may make it difficult to see the devices and links against the background. To make the image more suitable as a background image, you may use a graphics program to increase the brightness and/or decrease its contrast before placing it in a map. We regularly use GraphicConverter, an inexpensive shareware graphics program from http://www.lemkesoft.com, to do this task. It has a Brightness/Contrast adjustment facility to simplify this task.

Be aware of image file size

Large images consume large amounts of memory and slow InterMapper's redrawing of the window, especially when viewed over a remote connection. You should balance the image quality against the size of the map. Larger maps may look better, but they may consume large amounts of memory.

Note: Use of a compressed image file format such as JPG does not necessarily translate into less memory use.

Use contrast and compression to reduce image file size

Decreasing contrast can decrease the size of an image, so that decreasing the contrast as described above may help decrease the size of the background image as well. Use compressed formats, such as JPG and GIF, to further decrease the overall size of the image file.
